YS-1000B Semi-auto Component Taping Machine
Product Overview
The YS-1000B Semi-auto Component Taping Machine is a precision-engineered solution for efficient component packaging and taping operations in electronic manufacturing environments.
Key Features
- Adjustable track width from 8mm to 72mm with easy-to-operate control screen
- Fine adjustment head in hot-press device with 0.1±mm precision and independent PID temperature control
- Cover tape position fine adjustment through moving tape tension control
- Fiber-optic counting system with leakage detection for accurate braiding
- Continuously adjustable moving tape speed with pedal control, compatible with ELA-481 standard plastic reels
Technical Specifications
| Model |
YS-1000B |
| Inspection System |
CCD Check Function |
| Machine Dimensions |
1650 × 460 × 580mm (L × H × W) |
| Feeding Compatibility |
ELA-481 standard wheel and cover tape |
| Tape Width Range |
12mm-72mm (8mm requires customization) |
| Power Supply |
AC200V 50HZ |
| Operating Pressure |
3.0kg/cm² |
| Temperature Control |
Dual-head independent PID control, range 20-200°C |
| Taping Speed |
3000-7000 PCS/hour (component dependent) |
| Counting System |
Fiber-optic sensitive counter |
| Package Type |
Self-adhesive or hot sealing |
| Weight |
50KG |
